3D Formica White Laminate 2/2/0.5mm Microperforated Acoustic Panels Soundproofing Board

Basic Information

Place of Origin:	China
Brand Name:	Brotex Acoustic
Certification:	FSC / ISO / SGS / Intertek
Model Number:	2/2/0.5mm

Minimum Order Quantity:	50㎡
Price:	$95.42 -$105.98 /㎡
Packaging Details:	Carton / Pallet
Delivery Time:	2.5-3 weeks
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	5000 ㎡/ month

Get Best Price Contact Now

Detail Information

Finish:	Real Veneer / Laminate / Melamine	Laminate:	Lamitak / Formica / TBC
Fleece:	Soundtex / Freudenberg	Standard Core Thick:	15mm / 18mm / TBC
Edge Option:	Type A / Type C	Application:	Auditorium / Conference Hall / School / Office
Highlight:	3D Formica white laminate acoustic panels , microperforated soundproofing board 2mm , acoustic panels with warranty

Product Description

3D Formica White Laminate 2/2/0.5mm Microperforated Acoustic Panels Soundproofing Board

Product Specifications

Attribute	Value
Finish	Real Veneer / Laminate / Melamine
Laminate	Lamitak / Formica / TBC
Fleece	Soundtex / Freudenberg
Standard core thick	15mm / 18mm / TBC
Edge option	Type A / Type C
Application	Auditorium / Conference hall / School / Office

Core Product Features

Perforation Patterns	1.8/1.8/0.5mm, 2/2/0.5mm, 3/3/0.5mm
Surface Finishes	Real wood veneer / laminate / melamine
Core Materials	Charcoal board / MDF
Acoustic Backing	Soundtex / Freudenberg
Standard Dimensions	1200×600mm / 2400×1200mm / Custom
Core Thickness	15mm / 18mm / Custom
Perforation Shapes	Square / Rhombic
Edge Profiles	Type A (90° clean cut) / Type C (凹 all sides)
Grain Orientation	Lengthwise / Widthwise

Product Advantages

Exceptional Acoustics: NRC 0.90 (ISO 354:2003 certified)
Premium Aesthetics: Natural wood to high-gloss finishes
Custom Design: Unperforated borders & adjustable spacing
Easy Installation: Z-clip wall / T-grid ceiling systems
Sustainable: FSC certified with 70.8% recycled content

Technical Performance

Fire Safety: Class A (ASTM E84-15b)
Air Quality: Complies with ISO 16000 standards
Custom Sizing: Up to 3050×1220mm panels available

Veneer Options

12 standard wood veneers
Custom slip-matched & sample-matched options
Various stain colors available

Quality Notes

Natural wood variations may occur
Stained samples provided for approval
Production begins after client confirmation

Installation & Packaging

Secure pallet packaging
Comprehensive installation guidance
Project references available
